Hooklift System
Hydraulic hooklift for roll-off containers, 5 models with 5.5 to 18 t lift capacity, jib height 1,500–1,600 mm and overall length from 3,800 mm to 5,880 mm.
Models: H&H series, 5 models
- lift capacity
- 5.5 / 6 / 18 t
- self weight
- 1,000 – 2,600 kg
- jib height
- 1,500 – 1,600 mm
- overall length
- 3,800 – 5,880 mm
- secondary beam width
- 750 / 850 mm
- models listed
- 5
Full specifications by model
Every row below is one orderable model. Link straight to a model with its anchor — for example #h-h-3660-750.
| Model | Lift Capacity | Total Self Weight | Jib Height | Over Length | Secondary Beam Width |
|---|---|---|---|---|---|
| H&H-3660*750 | 5.5 tons | 1000 Kgs | 1500 mm | 3800 mm | 750 mm |
| H&H-3660*850 | 5.5 tons | 1050 Kgs | 1500 mm | 3800 mm | 850 mm |
| H&H-4150*750 | 6 tons | 1100 Kgs | 1500 mm | 4200 mm | 750 mm |
| H&H-4150*850 | 6 tons | 1150 Kgs | 1500 mm | 4200 mm | 850 mm |
| H&H-5880*850 | 18 tons | 2600 Kgs | 1600 mm | 5880 mm | 850 mm |
Dimensions are in millimetres and are taken from the current drawing for each model. Before ordering, ask us for the drawing of the exact model so the mounting dimensions are checked against your frame — the table is for selection, the drawing is what we build to.
Dimensional drawings
Each series has its own drawing with the mounting interfaces, cylinder support and cradle options. Open a drawing full size to read the tolerances and thread options.
Where this cylinder is used
Selection is driven by the duty cycle, not the catalogue. Tell us the load, the stroke you need and how many cycles per day — those three numbers decide the series and often the port configuration.
- roll-off-containers
- skip-loading
- waste-and-scrap
Questions buyers ask before ordering
- What lift capacity do the five models cover?
- 5.5 t on the two 3,660 mm models, 6 t on the two 4,150 mm models, and 18 t on the 5,880 mm model. The jump to 18 t comes with a self weight of 2,600 kg, which is a chassis specification question as much as a hydraulic one.
- What is secondary beam width and why does it matter?
- It is the width of the subframe that sits on the chassis rails — 750 mm or 850 mm here. It has to match your chassis width; the two are not interchangeable without modifying the frame.
- What is jib height?
- 1,500 mm on the smaller models and 1,600 mm on the 18 t unit. It is the height of the hook arm pivot, and it determines the hook height the container needs to be picked from.
- Does the drawing show the valve arrangement?
- Yes. The layout drawing labels the base frame, lift cylinder, hook arm, secondary lifting arm and the multiple directional control valve, so you can see where the hydraulic plumbing runs before quoting.
